Machine Characters: Basic Type
Cutting Power (kW): 2x180
Cutting Height (m): 2.6~4.6
Cutting Width (m): 3.3
Production Capacity (t/min): 15~27
Economic Cutting Hardness (MPa): ≤40
Cutting Dinting Volume (m): 0.2
Installed Power (kW): 647
Machine Weight (t): 62
Ground Pressure (MPa): 0.19
Ground Clearance (m): 0.3
Adaptive Slope (°): ≤17°
Traction Power (kW): 2x60
Walking Speed (m/min) : 4.5/9/20
Supply Voltage (VAC): 1140
Outline Dimension (m): 11.3x3.3x2
Crawler Frame: 3.6x0.9x1.1
Cutting Arm: 3.46x1.55x1.16
Conveyor: 4.8x1.35x1.36
Crawler Frame: 6.9
Cutting Arm: 4.2
Conveyor: 2.5
The series is complete and diverse with strong adaptability, meeting the mining height requirements of 1.3m-5.5m.
2x 180kW powerful cutting mechanism, equipped with triple overload protection device.
2x 60kW four-quadrant AC variable frequency speed regulation traction system, running smoothly and with strong maneuverability.
The main hydraulic and electrical components adopt international high-end brands.
On-board negative-pressure wet-type dust remover, combined with cutting internal and external spray for efficient dust removal.
Adopt modular and split design, easy to disassemble and maintain, convenient for underground transport.
Three control options available
The monitoring and diagnosis system and safety protection devices are sound and reliable.
The continuous mining machine has remote monitoring and control interfaces and can achieve intelligent excavation by upgrading the matching laser-integrated inertial navigation system and central controller.
